Lab Summary:
|
Sr. No. |
Existing UG Labs |
Existing PG Labs |
| 1 |
CAD/CAM |
Computer Lab 1 |
| 2 |
Thermodynamics Lab |
Computer Lab 2 |
| 3 |
Fluid Mechanics Lab |
Research Lab |
| 4 |
Heat Transfer Lab |
|
| 5 |
Metallurgy Lab |
|
| 6 |
Theory of Machines Lab |
|
| 7 |
Engineering Graphics Lab |
|
| 8 |
Systems in Mechanical Engineering Lab |
|
| 9 |
Dynamics of Machinery Lab |
|
| 10 |
Project Lab |
CAD/CAM
|
Hardware |
Computers(59), Laptop(04), Printer(07), Plotter (01) |
|
Software |
CATIA V5RN1, ANSYS13.0, MATLAB7.0, UG7.5(NX), AutoCAD2013, Abaqus |
|
Practicals Conducted |
FEM, Geometric Modeling, CONM, CCA, CAMD |
|
Latest Computers, Latest Software with License copy, Projectors for Presentation |
|
Thermodynamics Lab
|
Hardware |
Computer(01) |
|
Software |
Ni-DAQ, TAMMONA |
|
Practical Conducted |
Computerized Multi cylinder SI Engine Test Rig , Computerized Air Conditioning Test Rig, Vapor Computerized Test Rig , Hydrogen Fluid Test Rig , Twine Diesel Test Rig , Multi Stage Reciprocating Computerized Test Rig , Cut Section model of Single Cylinder Petrol and Diesel Engine , Five Gas Analyzer (AVL Make), CNG Fuel Test Rig. |
Fluid Mechanics Lab
|
|
|
|
Hardware |
-- |
|
Software |
-- |
|
Practical Conducted |
Fluid Mechanics ,Turbo Machines , Industrial Fluid Power |
|
Practical Oriented Models Like Pelton Turbine , Francis Turbine , Kaplan Turbine , Hydro Trammel Kit , Vane Pump |
|
Heat Transfer Lab
|
|
|
|
Hardware |
Computers(02) |
|
Software |
Stefan Boltzmann – in-VB6 |
|
Practicals Conducted |
Heat Transfer |
|
Computer interface-Stefan Boltzmann Apparatus, Plate Type of Heat Exchanger, SAP Group, LCD-TV |
|
Metallurgy & Mechatronics
|
|
|
|
Hardware |
Computers(5), Scanner (01), Printer (01) |
|
Software |
Microstructure interpreter software, Ladder Programming Software |
|
Practical Conducted |
Hardness Testing & Metallography, NDT, Different Sensors & Transducers |
|
Hardens ability tester and Jominy End Quench Test, Data Acquisition System, Practical Demo video, PPT, Load Cell Trainer Kit, Linear Conveyor Control System, Analog Model PLC-II Kit, Water level Control System, Universal IC Trainer, 20 sim tm 3.6 Professional with FORSEE Toolkit for RTAI & ARM9 Protoboard (Departmental License), Capacitance level transducer trainer, LVDT, RTD Calibrated setup |
|
Theory of Machines Lab
|
|
|
|
Hardware |
Computers(05), Scanner(01), Printer (01) |
|
Software |
-- |
|
Practical Conducted |
Theory of Machines, Dynamic of Machinery |
Engineering Graphics
|
|
|
|
Hardware |
Computers(29) |
|
Software |
AutoCaD2013, CATIA V5R19 |
|
Practical Conducted |
Engineering Graphics II, CAMD |
Systems in Mechanical Engineering Lab
Dynamics of Machinery Lab
Project Lab
DEPARTMENT OF MECHANICAL ENGINEERING [ DESIGN & HEAT POWER LAB]
| Hardware | Computers (36), Printers (01) |
| Software | CATIA V5RN1, ANSYS13.0, HYPERMESH, ABAQUS, MATLAB7.0, UG7.5(NX) |
| Practical Conducted | Machine design and Heat power |
Machine Design & Heat Power Labs
Design Lab:
Heat Power Lab:
| Sr. No. | Particulars | Nos. |
| 1 | List of Books Purchased through AICTE Grant | 37 |
| 2 | Details of Books gifted by staff | 83 |
| 3 | Gifts from publisher & staff | 406 |
| 4 | Extra | 163 |
| 5 | Total No Of Books in central library | 6853 |
| 6 | Total | 7542 |
